ITEM NO. |
RATED CURRENT(A) |
SECTION SIZE (mm2) |
L (mm) |
W (mm) |
H (mm) |
A (mm) |
B (mm) |
φd (mm) |
|
H-3 |
3 |
2.5/4 |
92 |
16 |
12.2 |
5.5 |
7.5 |
2.7 |
|
H-6 |
6 |
6 |
119 |
17.3 |
13.9 |
6.5 |
8.2 |
3.3 |
|
H-10 |
10 |
10 |
131 |
20.85 |
16.4 |
7.25 |
11.2 |
3.71 |
|
H-15 |
15 |
12 |
135 |
22.65 |
18.25 |
8.25 |
11.5 |
4.2 |
|
H-20 |
20 |
14 |
141.6 |
22.65 |
18.4 |
8.5 |
12.2 |
4.5 |
|
H-30 |
30 |
16 |
165 |
24.1 |
21.1 |
9.5 |
14.1 |
5.5 |
|
H-60 |
60 |
25 |
190 |
30.8 |
25.2 |
11.15 |
16.5 |
6.3 |
|
H-80 |
80 |
30 |
201 |
36 |
22.65 |
12.1 |
18.15 |
6.9 |
|
H-100 |
100 |
35 |
228 |
38 |
33 |
13.8 |
19.4 |
7.4 |
|
H-150 |
150 |
40 |
261 |
44 |
33 |
21.2 |
22 |
8.3 |
