ITEM NO. |
φd(mm) |
φE(mm) |
φD(mm) |
W(mm) |
L2(mm) |
L1(mm) |
|
GPH90-6/5 |
3.5 |
5.3 |
6.5 |
10.0 |
14.0 |
22.5 |
|
GPH90-6/6 |
6.4 |
12.0 |
24.0 |
|||
|
GPH90-6/8 |
8.4 |
15.0 |
27.5 |
|||
|
GPH90-6/10 |
10.5 |
16.0 |
29.5 |
|||
|
GPH90-10/5 |
4.5 |
5.3 |
7.0 |
12.0 |
16.0 |
23.0 |
|
GPH90-10/6 |
6.4 |
12.0 |
24.0 |
|||
|
GPH90-10/8 |
8.4 |
15.0 |
28.0 |
|||
|
GPH90-10/10 |
10.5 |
18.0 |
29.5 |
|||
|
GPH90-16/5 |
5.5 |
5.3 |
8.5 |
12.0 |
20.0 |
22.5 |
|
GPH90-16/6 |
6.4 |
14.0 |
24.0 |
|||
|
GPH90-16/8 |
8.4 |
15.0 |
28.0 |
|||
|
GPH90-16/10 |
10.5 |
18.0 |
31.0 |
|||
|
GPH90-16/12 |
13.0 |
19.0 |
32.0 |
|||
|
GPH90-25/6 |
6.9 |
6.4 |
10.0 |
15.0 |
21.0 |
27.5 |
|
GPH90-25/8 |
8.4 |
16.0 |
32.5 |
|||
|
GPH90-25/10 |
10.5 |
18.0 |
32.5 |
|||
|
GPH90-25/12 |
13.0 |
19.0 |
34.0 |
|||
|
GPH90-35/6 |
8.5 |
6.4 |
12.0 |
17.0 |
24.0 |
28.5 |
|
GPH90-35/8 |
8.4 |
17.0 |
34.0 |
|||
|
GPH90-35/10 |
10.5 |
20.0 |
34.0 |
|||
|
GPH90-35/12 |
13.0 |
22.0 |
40.5 |
|||
|
GPH90-50/6 |
10.0 |
6.4 |
14.0 |
20.0 |
28.5 |
37.0 |
|
GPH90-50/8 |
8.4 |
20.0 |
40.5 |
|||
|
GPH90-50/10 |
10.5 |
20.0 |
40.5 |
|||
|
GPH90-50/12 |
13.0 |
23.0 |
42.5 |
|||
|
GPH90-50/16 |
17.0 |
28.0 |
50.5 |
|||
|
GPH90-70/8 |
12.0 |
8.4 |
16.5 |
24.0 |
31.0 |
43.0 |
|
GPH90-70/10 |
10.5 |
24.0 |
43.0 |
|||
|
GPH90-70/12 |
13.0 |
24.0 |
44.5 |
|||
|
GPH90-70/16 |
17.0 |
28.0 |
53.0 |
|||
|
GPH90-70/20 |
21.0 |
30.0 |
59.0 |
|||
|
GPH90-95/8 |
13.5 |
8.4 |
18.0 |
26.0 |
35.0 |
44.5 |
|
GPH90-95/10 |
10.5 |
26.0 |
44.5 |
|||
|
GPH90-95/12 |
13.0 |
26.0 |
46.5 |
|||
|
GPH90-95/16 |
17.0 |
28.0 |
52.0 |
|||
|
GPH90-95/20 |
21.0 |
30.5 |
59.0 |
|||
|
GPH90-120/10 |
15.0 |
10.5 |
19.5 |
29.0 |
35.5 |
49.0 |
|
GPH90-120/12 |
13.0 |
29.0 |
49.0 |
|||
|
GPH90-120/16 |
17.0 |
29.0 |
55.0 |
|||
|
GPH90-120/20 |
21.0 |
30.5 |
61.0 |
|||
|
GPH90-150/10 |
16.5 |
10.5 |
21.0 |
31.0 |
40.0 |
48.0 |
|
GPH90-150/12 |
13.0 |
31.0 |
51.0 |
|||
|
GPH90-150/16 |
17.0 |
31.0 |
56.0 |
|||
|
GPH90-150/20 |
21.0 |
34.0 |
615 |
|||
|
GPH90-185/12 |
19.0 |
13.0 |
24.0 |
35.0 |
46.0 |
585 |
|
GPH90-185/16 |
17.0 |
35.0 |
585 |
|||
|
GPH90-185/20 |
21.0 |
35.0 |
65.0 |
|||
|
GPH90-240/12 |
21.0 |
13.0 |
26.0 |
40.0 |
50.0 |
54.0 |
|
GPH90-240/16 |
17.0 |
40.0 |
60.0 |
|||
|
GPH90-240/20 |
21.0 |
40.0 |
67.8 |
|||
|
GPH90-300/12 |
23.5 |
13.0 |
29.5 |
43.0 |
59.0 |
74.5 |
|
GPH90-300/16 |
17.0 |
43.0 |
64.0 |
|||
|
GPH90-300/20 |
21.0 |
43.0 |
70.5 |
|||
|
GPH90-400/12 |
27.0 |
13.0 |
34.0 |
49.0 |
62.0 |
79.0 |
|
GPH90-400/16 |
17.0 |
49.0 |
68.5 |
|||
|
GPH90-400/20 |
21.0 |
49.0 |
75.0 |
