ITEM NO. |
φd(mm) |
φE(mm) |
φD(mm) |
W(mm) |
B(mm) |
L(mm) |
|
DIN6-5 |
3.8 |
5.3 |
5.5 |
8.5 |
10.0 |
30.5 |
|
DIN6-6 |
6.4 |
8.5 |
31.5 |
|||
|
DIN6-8 |
8.4 |
13.0 |
34.0 |
|||
|
DIN10-5 |
4.5 |
5.3 |
6.0 |
9.0 |
10.0 |
34.0 |
|
DIN10-6 |
6.4 |
9.0 |
34.5 |
|||
|
DIN10-8 |
8.4 |
13.0 |
37.0 |
|||
|
DIN10-10 |
10.5 |
15.0 |
39.0 |
|||
|
DIN16-6 |
5.5 |
6.4 |
8.5 |
13.0 |
20.0 |
43.5 |
|
DIN16-8 |
8.4 |
13.0 |
46.0 |
|||
|
DIN16-10 |
10.5 |
17.0 |
48.0 |
|||
|
DIN16-12 |
13.0 |
18.0 |
49.0 |
|||
|
DIN25-6 |
7.0 |
6.4 |
10.0 |
14.0 |
20.0 |
45.5 |
|
DIN25-8 |
8.4 |
16.0 |
48.0 |
|||
|
DIN25-10 |
10.5 |
17.0 |
50.0 |
|||
|
DIN25-12 |
13.0 |
19.0 |
51.0 |
|||
|
DIN35-6 |
8.2 |
6.4 |
12.5 |
17.0 |
20.0 |
49.5 |
|
DIN35-8 |
8.4 |
17.0 |
52.0 |
|||
|
DIN35-10 |
10.5 |
19.0 |
54.0 |
|||
|
DIN35-12 |
13.0 |
21.0 |
55.0 |
|||
|
DIN35-14 |
15.0 |
21.0 |
56.5 |
|||
|
DIN 50-8 |
10.0 |
8.4 |
14.5 |
20.0 |
28.0 |
62.0 |
|
DIN50-10 |
10.5 |
22.0 |
64.0 |
|||
|
DIN50-12 |
13.0 |
24.0 |
65.0 |
|||
|
DIN50-14 |
15.0 |
24.0 |
66.5 |
|||
|
DIN50-16 |
17.0 |
28.0 |
68.0 |
|||
|
DIN70-8 |
11.5 |
8.4 |
16.5 |
24.0 |
28.0 |
65.0 |
|
DIN70-10 |
10.5 |
24.0 |
67.0 |
|||
|
DIN70-12 |
13.0 |
24.0 |
68.0 |
|||
|
DIN70-14 |
15.0 |
24.0 |
69.5 |
|||
|
DIN70-16 |
17.0 |
30.0 |
71.0 |
|||
|
DIN95-8 |
13.5 |
8.4 |
19.0 |
28.0 |
35.0 |
77.0 |
|
DIN95-10 |
10.5 |
28.0 |
77.0 |
|||
|
DIN95-12 |
13.0 |
28.0 |
78.0 |
|||
|
DIN95-14 |
15.0 |
28.0 |
79.5 |
|||
|
DIN95-16 |
17.0 |
32.0 |
81.0 |
|||
|
DIN120-10 |
15.5 |
5.3 |
21.0 |
30.0 |
35.0 |
85.0 |
|
DIN120-12 |
6.4 |
30.0 |
86.0 |
|||
|
DIN120-14 |
8.4 |
30.0 |
88.0 |
|||
|
DIN120-16 |
5.3 |
30.0 |
89.0 |
|||
|
DIN 120-20 |
6.4 |
38.0 |
91.0 |
|||
|
DIN150-10 |
17.0 |
8.4 |
23.5 |
34.0 |
35.0 |
93.0 |
|
DIN150-12 |
10.5 |
34.0 |
94.0 |
|||
|
DIN150-14 |
6.4 |
34.0 |
97.0 |
|||
|
DIN150-16 |
8.4 |
34.0 |
97.0 |
|||
|
DIN150-20 |
10.5 |
40.0 |
99.0 |
|||
|
DIN185-10 |
19.0 |
13.0 |
25.5 |
37.0 |
40.0 |
97.0 |
|
DIN185-12 |
6.4 |
37.0 |
98.0 |
|||
|
DIN185-14 |
8.4 |
37.0 |
101.0 |
|||
|
DIN185-16 |
10.5 |
37.0 |
101.0 |
|||
|
DIN185-20 |
13.0 |
40.0 |
103.0 |
|||
|
DIN240-12 |
21.5 |
6.4 |
29.0 |
42.0 |
40.0 |
108.0 |
|
DIN240-14 |
8.4 |
42.0 |
111.0 |
|||
|
DIN240-16 |
10.5 |
42.0 |
111.0 |
|||
|
DIN240-20 |
13.0 |
45.0 |
113.0 |
|||
|
DIN300-12 |
24.5 |
15.0 |
32.0 |
46.0 |
50.0 |
119.0 |
|
DIN300-14 |
8.4 |
46.0 |
119.0 |
|||
|
DIN300-16 |
10.5 |
46.0 |
119.0 |
|||
|
DIN300-20 |
13.0 |
46.0 |
122.0 |
|||
|
DIN400-14 |
27.5 |
15.0 |
38.5 |
55.0 |
70.0 |
140.0 |
|
DIN400-16 |
17.0 |
55.0 |
140.0 |
|||
|
DIN400-20 |
8.4 |
55.0 |
140.0 |
|||
|
DIN500-16 |
31.0 |
10.5 |
42.0 |
60.0 |
70.0 |
150.0 |
|
DIN500-20 |
13.0 |
60.0 |
150.0 |
|||
|
DIN625-16 |
34.5 |
15.0 |
44.0 |
64.0 |
80.0 |
160.0 |
|
DIN625-20 |
17.0 |
64.0 |
160.0 |
|||
|
DIN800-16 |
40.0 |
8.4 |
52.0 |
75.0 |
100.0 |
195.0 |
|
DIN800-20 |
10.5 |
75.0 |
195.0 |
|||
|
DIN1000-16 |
44.0 |
13.0 |
58.0 |
85.0 |
100.0 |
195.0 |
|
DIN1000-20 |
15.0 |
85.0 |
195.0 |
