ITEM NO. |
φd(mm) |
φE(mm) |
φD(mm) |
W(mm) |
B(mm) |
L(mm) |
H（mm） |
|
CL14-2H-6 |
5.8 |
6.4 |
8.8 |
13.0 |
28.5 |
117.5 |
45.0 |
|
CL22-2H-8 |
7.7 |
8.4 |
11.3 |
16.0 |
28.5 |
119.2 |
45.0 |
|
CL38-2H-10 |
9.8 |
10.5 |
12.4 |
18.3 |
31.7 |
120.0 |
45.0 |
|
CL38-2H-12 |
13.0 |
18.3 |
|
45.0 |
|||
|
CL60-2H-10 |
11.0 |
10.5 |
14.0 |
20.5 |
40.0 |
130.0 |
45.0 |
|
CL60-2H-12 |
13.0 |
20.5 |
|
45.0 |
|||
|
CL70-2H-10 |
12.0 |
10.5 |
15.0 |
21.4 |
40.0 |
130.0 |
45.0 |
|
CL70-2H-12 |
13.0 |
21.4 |
|
45.0 |
|||
|
CL80-2H-12 |
13.0 |
13.0 |
16.0 |
23.2 |
40.0 |
130.0 |
45.0 |
|
CL100-2H-12 |
14.0 |
13.0 |
18.0 |
26.0 |
42.0 |
132.0 |
45.0 |
|
CL125-2H-12 |
16.0 |
13.0 |
20.0 |
29.0 |
42.0 |
135.0 |
45.0 |
|
CL150-2H-12 |
17.0 |
13.0 |
22.0 |
31.5 |
50.0 |
150.0 |
45.0 |
|
CL180-2H-12 |
18.2 |
13.0 |
23.0 |
33.0 |
50.0 |
150.0 |
45.0 |
|
CL200-2H-12 |
20.0 |
13.0 |
26.0 |
37.0 |
52.5 |
150.0 |
45.0 |
|
CL250-2H-12 |
22.0 |
13.0 |
28.0 |
40.0 |
50.0 |
150.0 |
45.0 |
|
CL325-2H-12 |
25.0 |
13.0 |
32.0 |
46.0 |
68.0 |
180.0 |
45.0 |
|
CL400-2H-12 |
30.0 |
13.0 |
37.0 |
54.0 |
60.0 |
180.0 |
45.0 |
|
CL500-2H-12 |
31.0 |
13.0 |
40.0 |
57.5 |
60.0 |
180.0 |
45.0 |
|
B-CL14-2H-6 |
5.8 |
6.4 |
8.3 |
13.0 |
28.5 |
117.5 |
45.0 |
|
B-CL22-2H-8 |
7.7 |
8.4 |
10.7 |
16.0 |
28.5 |
119.2 |
45.0 |
|
B-CL38-2H-10 |
9.8 |
10.5 |
11.9 |
17.5 |
31.7 |
120.0 |
45.0 |
|
B-CL38-2H-12 |
13.0 |
17.5 |
|
45.0 |
|||
|
B-CL60-2H-10 |
11.0 |
10.5 |
13.5 |
19.5 |
40.0 |
130.0 |
45.0 |
|
B-CL60-2H-12 |
13.0 |
19.5 |
|
45.0 |
|||
|
B-CL70-2H-10 |
12.0 |
10.5 |
14.5 |
21.4 |
40.0 |
130.0 |
45.0 |
|
B-CL70-2H-12 |
13.0 |
21.4 |
|
45.0 |
|||
|
B-CL80-2H-12 |
13.0 |
13.0 |
15.5 |
23.2 |
40.0 |
130.0 |
45.0 |
|
B-CL100-2H-12 |
14.0 |
13.0 |
17.3 |
26.0 |
42.0 |
132.0 |
45.0 |
|
B-CL125-2H-12 |
16.0 |
13.0 |
19.3 |
28.0 |
42.0 |
135.0 |
45.0 |
|
B-CL150-2H-12 |
17.0 |
13.0 |
21.1 |
31.0 |
50.0 |
150.0 |
45.0 |
|
B-CL180-2H-12 |
18.2 |
13.0 |
22.1 |
33.0 |
50.0 |
150.0 |
45.0 |
|
B-CL200-2H-12 |
20.0 |
13.0 |
24.9 |
36.0 |
50.0 |
150.0 |
45.0 |
|
B-CL250-2H-12 |
22.0 |
13.0 |
26.9 |
39.0 |
50.0 |
150.0 |
45.0 |
|
B-CL325-2H-12 |
25.0 |
13.0 |
30.7 |
45.0 |
68.0 |
180.0 |
45.0 |
|
B-CL400-2H-12 |
30.0 |
13.0 |
35.7 |
54.0 |
60.0 |
180.0 |
45.0 |
|
B-CL500-2H-12 |
31.0 |
13.0 |
38.4 |
56.0 |
60.0 |
180.0 |
45.0 |
